Description
All Features:
- 1 1/2″ x 3″ Tubular Welded Frame
- Magnetic Pin Height Adjustment
- Key Switch Panel
- Foot Operated Deck Lift
- Automatic Parking Brake
- Hydro-Gear ZT-2200 Transmission
- 5 gal Fuel Capacity
- 4″ Deck Height
Specifications:
- Engine
- Engine Name: Kawasaki FR691
- Horsepower: 23 HP
- Fuel Capacity: 5 Gallons
- Drive Line
- Hydraulic Drive: Hydro-Gear ZT-2200
- Front Tires: 12″ Bias Ply
- Drive Tires: 20″ Carlisle Turf Armor
- Wheel Type: Steel
- Speed (F/R): Forward – Up to 8 mph | Reverse – Up to 5 mph
- Features – Cutting Deck
- Deck Size: 42″
- Deck Depth: 4″
- Deck Lift: Foot Operated
- Deck Adjustment: Magnetic Pin Height Adjustment
- Cut Height: 1″ to 4.25″ with 12 Cut Heights
- Parking Brake: Automatic
- Measurements
- Width: 42″ Deck – 43.5″ Wide
- Weight: 682 – 719 lbs
- Length: 81″
- Height: 44″
- Warranty
- Full Warranty: 3 Year – 120 Day Belt Warranty
- Engine Warranty: 3 Year
- Deck Warranty: Lifetime on the leading edge
- Hydraulic Drive Warranty: 3 Year / 200 Hour
- Control Panel Warranty: Not Applicable
